HIKVISION DS-7608NXI-K1/8P(D) Network video recorder series NXI-K, up to 8 network cameras up to 12MP, e

In previous generations of Hikvision IP Recording NVRs (NI-Q, NI-K, etc.), we could connect Acusense technology IP Cameras, achieving artificial intelligence functions like Motion Detection 2.0, based on deep learning algorithms running on the cameras. That is, we could not distinguish the cause that triggered the alarm (human, vehicle, or other source) unless the camera supported Acusense technology to provide these functions.

Now, in the new NXI-K AcuSense NVR series, the Motion Detection 2.0 artificial intelligence algorithms are also offered by the NVR itself, across all channels of the recorder, even for simple IP cameras, reducing false alarms with human/vehicle classification. The HIKVISION Motion Detection 2.0 algorithm records all motion events, like the traditional algorithm. However, it also records the cause of the alarm, whether it is due to a person, vehicle, or other reason.

In the playback bar, events are marked differently for each cause, making it easy and quick to search for actual events during playback. Additionally, notifications sent to Hik-Connect or iVMS-4200 are limited only to events involving humans and vehicles.

The DS-7608NXI-K1(D) NVR supports up to 8 IP cameras, with a maximum resolution of 12MPixels. The total incoming bandwidth of connected cameras (Incoming Bandwidth) is 80Mbps. The total outgoing bandwidth (Outgoing Bandwidth) is also 80 Mbps. It features one (1) HDMI output up to 4K resolution (3840 × 2160) and one VGA output with a maximum resolution of 1920x1080. Supports decoding (simultaneous channel playback) of 8 channels.

Also, note that it can accept up to 1 SATA HDD (max 16TB - hard drive not included), and has one analog audio input/output (RCA In / RCA Out).

Motion Detection 2.0
From the recorder: On all channels, up to 4MP resolution (when enhanced SVC mode is enabled, up to 8 MP)
From the cameras: On all channels
Perimeter Detection (Intrusion Detection / Line Crossing):
From the recorder: Up to 1 channel from simple IP cameras, maximum resolution 4MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarms
From the cameras: On all channels
⚠️ Note: Facial recognition, Motion Detection 2.0, or Perimeter Protection functions on simple cameras cannot be enabled simultaneously.

The Acusense NVRs of the NXI-K series also have the ability to detect and recognize faces from 1 simple IP camera or from 4 IP cameras supporting face capture. Images are compared against a database of up to 10,000 photos, organized into libraries (up to 16). Each image must be up to 512 kB in size, and the total database size should be less than 150 MB.

It can be set to trigger an alarm if a face belonging to a blacklist appears or if a foreign face appears. During playback, filters based on photo or name can be selected for easy search of recorded videos.

⚠️ Human/vehicle classification functions on simple cameras and face recognition cannot be selected simultaneously (choose one of the two).

Main Features:
Up to 8-ch IP camera inputs
H.265+/H.265/H.264+/H.264 video formats
Up to 12 MPixels resolution recording
Up to 80Mbps incoming bandwidth
Adopt Hikvision Acusense technology to minimize manual effort and security costs
Support 1-ch HDMI Output at up to 4K (3840x2160) resolution and 1-ch VGA Output at up to 1080p
1x SATA interface
Motion Detection 2.0 (Human/Vehicle Analysis): 8-ch
Perimeter Protection (Human/Vehicle Analysis): 1-ch, 4 MP (HD network camera, H.264/H.265) video analysis for human and vehicle recognition to reduce false alarms
Ethernet Ports: 1
Support dual-OS to ensure high reliability of system operation
Support various VCA detection alarms and VCA search
Maximum total bandwidth:
Incoming bandwidth: 80Mbps
Outgoing bandwidth: 80Mbps
Decoding Support:
Decoding Format: H.265 / H.265+ / H.264+ / H.264
Recording Resolution: 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p
Synchronous playback: 8-ch
Decoding Capability when AI is on: 2-ch@12 MP (30 fps) / 3-ch@8 MP (30 fps) / 6-ch@4 MP (30 fps) / 12-ch@1080p (30 fps)
Decoding Capability when AI is off: 2-ch@12 MP (30 fps) / 4-ch@8 MP (30 fps) / 8-ch@4 MP (30 fps) / 16-ch@1080p (30 fps)
Stream Type: Video, Video & Audio
Audio Compression: G.711ulaw / G.711alaw / G.722 / G.726 / AAC
Supports IP cameras with resolutions:
12MPixels, 8MPixels, 6MPixels, 5MPixels, 4MPixels, 3MPixels, 2MPixels (1080p), 1MPixel 720p
Mobile phone support:
Android: Free application iVMS-4500 or Hik-Connect
iOS (iPhone): Free application iVMS-4500 or Hik-Connect
H.265+ compression offers significant reduction in data volume, resulting in substantial benefits in required bandwidth and storage space.
